Gasoline pumps
Your current location: home > PRODUCT CATEGORY > Water Pumps > Gasoline pumps >
| Name | self-suction pump |
| Model | YGS QGZ100-55G |
| Suction/discharge port diamter( mm) | 100（4″)/100（4″) |
| Total head lift(m) | 55 |
| Suction head lift（m） | 7 |
| Discharge capacity（m³/h) | 98 |
| Fuel tank capacity（L） | 6.5 |
| Fuel consumption（g/kW·h） | ≤374 |
| Net weight（kg） | 38 |
| Demensions(L×W×H)（mm） | 655×470×550 |
| Engine | 177F/P |
| Displacement（ml） | 270 |
| rpm/Rated power（kW） | 4.5/3600 |
| Oil capacity（L） | 1.1 |
